SWITCHES
DW MULTI-SWITCH – SERIES 66000 & 67000 PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
DW MULTI-SWITCH
SERIES 66000 and 67000
SERIES DW40 COLOR INSERTS
Many unusual lighting effects can be created using DW40 color
inserts. Molded from dimensionally stable, high-temperature
plastic in six standard colors, inserts slip into standard Series
DW300 pushbuttons providing unusual latitude in custom
designing color and legend effects. With no wear from finger-tips,
Series 66000 (non-illuminated) and 67000 (illuminated) can
be supplied with up to 18 stations, including a square white
legend life is virtually unlimited.
pushbutton Part Number DW305 at each station. Contacts and
Part No.
Color
Part No.
Color
Part No.
Color
ratings are the same as for Series 65000. Lamp sockets
(67000) at each station accept 6V to 28V T 1-3/4 flange base
lamps (not supplied). Mounts with 2 #6-32 machine screws
(not supplied). See page 310 for pushbutton data. Accessories
include solenoid release, ganged assemblies, T1 lamp
? DW41 Red ? DW44 Blue ? DW47 Orange
? DW43 Green ? DW45 White ? DW48 Yellow
? Special order only; Contact Switchcraft for price and delivery information.
SERIES DW300 PUSHBUTTONS (DW305 supplied standard)
adapter, and metal barriers (between stations). PC and
wire-wrapping terminals are also available. Contact Switchcraft.
NON-ILLUMINATED DW MULTI-SWITCH SWITCHES
Switchcraft offers DW Multi-Switch switches, Series 70000
Part No.
DW301
DW302
DW303
Color 1
Red
Black
Green
Part No.
DW304
DW305
DW308
Color 1
Blue
White
Yellow
Part No.
DW312
DW313
DW316
Color 1
Clear
Amber
“Black-
and 71000 with crossbar plungers which accept a wide variety
of Switchcraft and industry pushbuttons. Contact Switchcraft
for specifying assistance.
Screen”
1 Other colors available on special order. Buttons are 0.594 (15.09) x 0.594 (15.09)
PART NUMBERS/2-C PER STATION 1
Interlock
Push-Lock/
Number of
with Lock-Out
67021K506
67041K506
67061K506
67081K506
67101K506
67121K506
Non-Lock
? 67022506
? 67042506
? 67062506
? 67082506
? 67102506
? 67122506
Push-Release
? 67027506
? 67047506
? 67067506
? 67087506
? 67107506
? 67127506
Stations 2
2
4
6
8
10
12
PART NUMBERS/4-C PER STATION 1
? 67021K512
? 67041K512
? 67061K512
? 67081K512
? 67101K512
? 67121K512
? 67022512
? 67042512
? 67062512
? 67082512
? 67102512
? 67122512
? 67027512
? 67047512
? 67067512
? 67087512
? 67107512
? 67127512
2
4
6
8
10
12
1. Switches with all-lock function are available on special order. Contact
Switchcraft.
2. Odd number of stations (3, 5, 7, 9, 11) are available. Switches with
13 through 18 stations also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
Squeeze upper and
lower surfaces of
pushbutton and
pull free of
plungers.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Next, grasp lamp with
lamp removal tool or
fingertips and snap-
out. Replace lamp
and pushbutton.
Finished in seconds!
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
